EPCC Projects

This section highlights the selected EPC experience. In order to ensure on time and state-of-the-art production
& processing solutions, the group capabilities and resources also available to PDIL.


Oil Stabilization Package
On Going

Location: Gambat South GPF-IV (Shahdadpur) Sindh
Client: Pakistan Petroleum Limited
Capacity: 1500BPD
Scope: Design & Supply of Oil Stabilization Package with PLC Control

Details

Oil Stabilization Package

Location: Gambat South GPF-IV (Shahdadpur) Sindh
Client: Pakistan Petroleum Limited
Capacity: 1500BPD
Scope: Design & Supply of Oil Stabilization Package with PLC Control

Major Equipments





Utilities





White Oil Pipeline MOGAS Project (WOPMP)
On Going

Location: Sindh, Punjab-Pakistan
Client: Pak-Arab Pipeline Co. Ltd. (PAPCO)
Capacity: Enhancement of WOP, 8.0 MTPA to 12.0MTPA
Scope: EPCC of Complete Facility

Details

White Oil Pipeline MOGAS Project (WOPMP)

Location: Sindh, Punjab-Pakistan
Client: Pak-Arab Pipeline Co. Ltd. (PAPCO)
Capacity: Enhancement of WOP, 8.0 MTPA to 12.0MTPA
Scope: EPCC of Complete Facility

Major Equipments





Utilities





Crude Distillation Unit Revamp Project
2017

Location: Karachi-Pakistan
Client: National Refinery Limited
Capacity: Enhanced from 50000 BPD to 53000 BPD
Scope: EPCC of CDU Revamp

Details

Crude Distillation Unit Revamp Project

Location: Karachi-Pakistan
Client: National Refinery Limited
Capacity: Enhanced from 50000 BPD to 53000 BPD
Scope: EPCC of CDU Revamp

Major Equipments





Utilities





Gambat Sout Gas Processing Facility (GPF-||) Project
2017

Location: Distt. Sanghar, Sindh-Pakistan
Client: Pakistan Petroleum Limited
Capacity: 50 MMSCFD Gas Processing
Scope: EPCC of Complete Facility.

Details

Gambat Sout Gas Processing Facility (GPF-||) Project

Location: Distt. Sanghar, Sindh-Pakistan
Client: Pakistan Petroleum Limited
Capacity: 50 MMSCFD Gas Processing
Scope: EPCC of Complete Facility.

Major Equipments

  • Wellhead Air Cooler
  • Inlet Separation
  • Feed Gas Compressor
  • Amine Purification Unit (MDEA Type)
  • HCDP Control Unit (Propane based Refrigeration Compressor Package)
  • Condensate Stabilization Unit
  • LPG Recovery Unit
  • Recycle Gas Compressor
  • Sales Gas Compressing & Metering
  • LPG Storage & Metering
  • Chemical Injection Packages

Utilities

  • Oil / Water Separation System
  • Fire & Gas Detection System
  • Fire Fighting & Protection System
  • Fuel Gas System
  • Flare System
  • Water Treatment Package
  • Instrument Air System & Nitrogen Generation System
  • Condendate Storage and Loading
  • Closed Drain System
  • Inceneration System
  • Hot Oil System
  • Power Generation Sys

Adhi LPG & NGL Recovery Plant |||
2016

Location: Dist. Rawalpindi, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 30 MMSCFD LPG 164 MPTD, NGL 5330 BPD
Scope: EPCC Complete Facility

Details

Adhi LPG & NGL Recovery Plant |||

Location: Dist. Rawalpindi, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 30 MMSCFD LPG 164 MPTD, NGL 5330 BPD
Scope: EPCC Complete Facility

Major Equipments

  • Inlet Header
  • Production Separator
  • Molecular sieve Gas & Liquid Dehydration Units
  • Dew Point Reduction Unit
  • Gas Chilling & Refrigeration Unit
  • Hot Oil System
  • Sales Gas
  • LPG & NGL Metering
  • CPI Package
  • Methanol Injection Skid
  • Chemical Injection Package
  • Turbo Gensets with waste Heat Recovery Unit

Utilities

  • Hot Oil Sump Vessel
  • Hot Oil Charge Pump
  • Hot Oil Makeup Pump
  • Intrument Air Dryer
  • Instrument Air Receiver

Makori Field Development Surface Facilities
2014

Location: Karak, KPK, Pakistan
Client: MOL Oil & Gas Company B.V
Capacity: Gas Processing 150 MMSCFD, LPG 427 MTPD, Oil 20000 BPD, Condensate 10000 BPD
Scope: EPCC of the Complete Processing Facility.

Details

Makori Field Development Surface Facilities

Location: Karak, KPK, Pakistan
Client: MOL Oil & Gas Company B.V
Capacity: Gas Processing 150 MMSCFD, LPG 427 MTPD, Oil 20000 BPD, Condensate 10000 BPD
Scope: EPCC of the Complete Processing Facility.

Major Equipments

  • Slug Catchers
  • Cryogenic Unit
  • Fractionation Unit
  • Sales Gas Compression
  • Sales Gas Metering
  • Condensate stabilization unit
  • Oil stabilization unit
  • Oil/Condensate/LPG Storage & Loading Facilities

Utilities

  • Fire & gas Detection System
  • Fire Fighting & Petroleum System
  • Fuel Gas System
  • Flare System (Warm & Cold)
  • Waste Water Treatment Package
  • Instrument Air System
  • Control System

Adhi EPF Upgradation Project
2013

Location: District Rawalpindi, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 25 MMSCFD Gas processing capacity
Scope: Adhi EPF Up-Gradation project & modification of existing separators

Details

Adhi EPF Upgradation Project

Location: District Rawalpindi, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 25 MMSCFD Gas processing capacity
Scope: Adhi EPF Up-Gradation project & modification of existing separators

Major Equipments

  • Gas Pre-Heater
  • Associate Gas Compressor
  • Oil Cooler
  • Modification in Existing DCS System
  • Emergency Shutdown System
  • Below Down Valve System

Utilities

  • Fire & Gas Detection System
  • Flare System

Sulfur Recovery Unit- Dakhani Expansion Project
2013

Location: Punjab, Pakistan
Client: Oil & Gas Development Company Ltd.
Capacity: 90 Metric Ton per day
Scope: Design, supply & Commissioning

Details

Sulfur Recovery Unit- Dakhani Expansion Project

Location: Punjab, Pakistan
Client: Oil & Gas Development Company Ltd.
Capacity: 90 Metric Ton per day
Scope: Design, supply & Commissioning

Major Equipments

  • Acid Gas Scrubber Unit
  • Waist Heat Reclaimer
  • Reaction Furnace
  • SRU Reactor
  • Sulfur Condensor
  • Sulfur Degassing Reactor
  • Molten Sulfur Transfer Pumps
  • Sulfur Pit

Utilities

  • DCS, ESD
  • Fire and Gas Detection
  • Steam Generation System
  • Steam Condensers

Standby Dehydration Unit
2009

Location: Sindh, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 130 MMSCFD
Scope: EPCC of Complete unit and integration with existing plant

Details

Standby Dehydration Unit

Location: Sindh, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 130 MMSCFD
Scope: EPCC of Complete unit and integration with existing plant

Major Equipments

  • Pre & Post Gas Filters
  • Glycol Contractor + Inlet Accessories
  • (Bubble Cap Tray type) incl. all accessories
  • Gas/Glycol Heat Exchangers
  • Glycol Flash Vessel
  • Glycol Re-boiler with Glycol Surge Vessel incl. all Accessories
  • Burner Management System (BMS)
  • Glycol Still Column + Strip Column
  • Glycol Skimmer Vessel/Accumulator
  • Glycol/Glycol Heat Exchanger
  • Glycol Filters (Particulate Charcoal)
  • Sales Gas Cooler
  • Gas Conditioning Skid
  • PLC based Control & Instrumentation System
  • PLC based ESD System
  • PLC based Flow Balancing System
  • Moisture Analyzer
  • Uninterruprte Power Supply for Control Systems

Manzalai Field Development Surface Facilities
2009

Location: NWFP, Pakistan
Client: MOL Oil & Gas Company B.V.
Capacity: 300 MMSCFD
Scope: EPCC of the Complete Processing Facility

Details

Manzalai Field Development Surface Facilities

Location: NWFP, Pakistan
Client: MOL Oil & Gas Company B.V.
Capacity: 300 MMSCFD
Scope: EPCC of the Complete Processing Facility

Major Equipments

  • Gathering Manifold/Valve Assemblies with Pig Stations
  • Inlet Separation System
  • Corrosion Inhibitor Injection Package
  • Methanol Injection Package
  • TEG based Glycol Dehydration
  • Sales Gas Compression Unit
  • Condensate Stabilization Unit
  • vent KO Drum & Vent Stack

Utilities

  • Fire System
  • Power Generation System
  • Fire & Gas Detection System
  • Diesel Storage System
  • Fire Fighting & Petroleum System
  • Produced Water Treatment Package
  • Fuel Gas System
  • Raw Water System
  • Condensate Storage & Loading
  • Instrument / Utility Air System
  • Flare System

El-Wastani Gas Field Development Project Ph-III
2006

Location: Damietta, Egypt
Client: El-Wastani Petroleum Co.
Capacity: 157 MMSCFD Ph-I & 153 MMSCFD Ph-II
Scope: Overall project management, construction supervision and commissioning of entire facility. All utilities on EPC basis

Details

El-Wastani Gas Field Development Project Ph-III

Location: Damietta, Egypt
Client: El-Wastani Petroleum Co.
Capacity: 157 MMSCFD Ph-I & 153 MMSCFD Ph-II
Scope: Overall project management, construction supervision and commissioning of entire facility. All utilities on EPC basis

Major Equipments

(Stage 1)

  • Mechanical Refrigeration
  • Glycol regeneration
  • Condensate Stabilization
  • Stabilizer Overhead Compression
  • Condensate Storage
  • metering & pumping facility

    (Stage 2)

  • Molecular Sieve Dehydration
  • Turbo Expander Train
  • De-Ethanizer, De-Butanizer
  • Overhead Gas Compression from De- Ethanizer, De-Butanizer
  • De-Ethanizer, De-Butanizer Units
  • LPG Recovery & Export System

Utilities

  • Diesel engine Driven Power Generators
  • Instrument Air System
  • Inert Gas System
  • Heat Medium System
  • Fire Fighting System
  • Produced Water Treatment System
  • Condensate Storage & Transfer System
  • Instrument Air System

Gurguri Gas Field Development Project
2005

Location: NWFP, Pakistan
Client: MOL Oil & Gas Company B.V.
Capacity: 50 MMSCFD
Scope: EPCC of the Complete Processing Facility

Details

Gurguri Gas Field Development Project

Location: NWFP, Pakistan
Client: MOL Oil & Gas Company B.V.
Capacity: 50 MMSCFD
Scope: EPCC of the Complete Processing Facility

Major Equipments

  • Inlet Cooler
  • Heat Exchanger
  • Separator Package
  • Glycol Based Dehydration
  • Hydrocarbon Dew Point Control
  • Turbo Expander Skid
  • Gas Metering

Utilities

  • Flare System
  • Power Generation System
  • Instrument Air System
  • Condensate Storage & Loading
  • Fire & Gas Detection System
  • Fire Water System

Rehmat Gas Field Development Project
2005

Location: Sindh, Pakistan
Client: Petronas Carigali (Pakistan) Limited
Capacity: 80 MMSCFD
Scope: EPCC of the Complete Processing Facility

Details

Rehmat Gas Field Development Project

Location: Sindh, Pakistan
Client: Petronas Carigali (Pakistan) Limited
Capacity: 80 MMSCFD
Scope: EPCC of the Complete Processing Facility

Major Equipments

  • Production manifold
  • Test Separator
  • Inlet Separator
  • Raw Gas Distribution & Blow down System
  • Amine Sweetening Unit
  • Hydrocarbon Dewpoint Control Unit (Scilica Gel based)
  • Refrigeration Unit
  • Gas metering Package

Utilities

  • Fuel Gas System
  • Heating Unit Medium
  • Power Generation system
  • Flare System
  • Acid Gas Incineration System
  • Chemical Injection System
  • Waste Water Treatment Package
  • Instrument Air System

Mazarani Gas Field Development Project
2003

Location: Sindh, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 12 MMSCFD
Scope: EPCC of the Complete Processing Facility

Details

Mazarani Gas Field Development Project

Location: Sindh, Pakistan
Client: Pakistan Petroleum Limited
Capacity: 12 MMSCFD
Scope: EPCC of the Complete Processing Facility

Major Equipments

  • Slug Catcher/ Three Phase Separator
  • MDEA based Amine Sweetening Unit
  • TEG based Dehydration Plant
  • First and Second Stage Natural Gas Compression unit
  • Sales Gas Metering System

Utilities

  • Flare System
  • Condensate Stablilization system
  • Power Generation System
  • Acid Gas Incineration System
  • Fire & Gas Detection System
  • Instrument / Plant Air System
 This is debug window. Set define('DEBUG', FALSE) in config.php file to hide it.
